Regenerative_Turbine_Pumps

One of the most important feature of NIKUNI regenerative turbine pumps is having its impellers fastened to the pump shafts, which is different from other similar pumps. The precise clearances between the impeller and pump body or pump cover are the prerequisite to obtain steady flow and head to ensure long-lasting performance and reliability. Strict engineering and quality control standards have been adopted in NIKUNI regenerative turbine pump manufacturing processes, assuring precision, parallelism, concentricity and overall allowance limits of all pump parts and final assembly precision of the pump. These help solving the problems of inevitable deteriorated performance and short life expectancy of many similar pumps with floating impellers caused by metal frictions, wears and tears in the pumps.
more..
Model name Product name Flow rate Total head Liquid temperature
KLD Bronze material, medium pressure application ~110L/min ~80m ～120℃／-V：～150℃
KPD Bronze material, high self-priming capability ~110L/min ~80m ～120℃／-V：～150℃
KHD Bronze material, high pressure (max. 1.1 MPa) ~110L/min ~110m ～120℃／-V：～150℃
KWD Bronze material, super high pressure (max. 2.0 MPa) ~50L/min ~200m ～120℃／-V：～150℃
DKL Lead-free copper material, excellent cost performance ~75L/min ~60m ～120℃
DKH Lead-free copper material, high pressure and excellent cost performance ~75L/min ~80m ～120℃
NED Stainless steel, medium pressure application ~120L/min ~60m ～150℃
NPD Stainless steel, self-priming capability ~170L/min ~60m ～90℃／-J：～80℃
NHD Stainless steel, high pressure (max. 1.1 MPa) ~50L/min ~110m ～150℃
NWD Stainless steel, super high pressure (max. 2.0 MPa) ~52L/min ~200m ～90℃
DNL Stainless steel, excellent cost performance ~40L/min ~52m ～120℃
DNH Stainless steel, high pressure and excellent cost performance ~20L/min ~80m ～120℃
ULD Stainless steel, high quality mechanical seal and packing ~100L/min ~50m ～90℃
UPD Stainless steel, high self-priming capability ~200L/min ~50m ～90℃
UND・UOD Stainless steel, low NPSH requirement ~75L/min ~35m ～90℃
JLD Stainless steel, super clean model ~60L/min ~50m ～90℃／-J：～80℃
JHD Stainless steel, super clean and high pressure (max. 1.1 MPa) ~60L/min ~110m ～90℃／-J：～80℃
FED Ferrous material, robust and low operation noise ~120L/min ~60m ～150℃
FHD Ferrous material, robust and high pressure (max. 1.1 MPa) ~100L/min ~110m ～150℃
TFD Ferrous material, high temperature liquid transfer (max. 230 ℃) ~90L/min ~60m ～230℃
KL Bronze material, medium pressure application ~110L/min ~80m ～150℃
KP Bronze material, high self-priming capability ~110L/min ~80m ～150℃
KH Bronze material, high pressure (max. 1.1 MPa) ~110L/min ~90m ～120℃／-V：～150℃
NE Stainless steel, medium pressure application ~120L/min ~60m ～150℃
NP Stainless steel, self-priming capability ~170L/min ~60m ～90℃
NH Stainless steel, high pressure (Max. 1.1MPa) ~50L/min ~110m ～150℃
UL Stainless steel, high quality mechanical seal ~86L/min ~50m ～90℃
UP Stainless steel, high self-priming capability (Max. -8 m) ~190L/min ~50m ～90℃
UN・UO Stainless steel, Low NPSH requirement model ~75L/min ~35m ～90℃
SN Stainless steel, high pressure for process application (Max. 1.4 MPa) ~105L/min ~170m ～90℃
SNWF Stainless steel, super high pressure for process application (Max. 3.0 MPa) ~110L/min ~300m ～90℃
TN Stainless steel, heavy-duty customized model ~130L/min ~150m ～120℃
SP Stainless steel, high versatility model ~1200L/min ~100m ～90℃
JL Stainless steel, super clean model ~58L/min ~50m ～90℃／-J：～80℃
JH Stainless steel, super clean and high pressure (max. 1.1 MPa) ~48L/min ~110m ～90℃／-J：～80℃
ST Ferrouos material, high pressure application (max. 1.7 MPa) ~105L/min ~170m ～90℃
STS Ferrouos material, high pressure application (max. 1.7 MPa) ~105L/min ~170m ～100℃
STW Ferrouos material, super high pressure application (max. 3.0 MPa) ~110L/min ~300m ～90℃
STWS Ferrouos material, super high pressure application (max. 3.0 MPa) ~110L/min ~300m ～100℃
FE Ferrous material, robust and low operation noise ~120L/min ~60m ～90℃
FH Ferrous material, robust and high pressure (Max. 1.1 MPa) ~100L/min ~110m ～90℃
TF Ferrous material, high temperature liquid transfer (Max. 350 ℃) ~135L/min ~40m ～350℃
BKX Compact size, bronze material canned pump ~14L/min ~60m -10～80℃
BNX Compact size, stainless steel canned pump ~14L/min ~50m -10～80℃
PNX Compact size, stainless steel permanent magnetic canned pump ~120L/min ~70m -10～90℃
GNLM Stainless steel, high versatility magnetic drive ~90L/min ~60m -10～150℃
NLMS Stainless steel, high versatility magnetic drive ~110L/min ~70m -100～200℃
NLMB Stainless steel, high versatility magnetic drive ~110L/min ~70m -100～200℃
TNM Stainless steel, heavy-duty magnetic drive model ~375L/min ~150m -100 ～ 250 ℃

Monoblock_model

Model nameProduct nameFlow rateTotal headLiquid temperature
Monoblock_model CAC_bronze
Model nameProduct nameFlow rateTotal headLiquid temperature
Monoblock_model Stainless_steel
Model nameProduct nameFlow rateTotal headLiquid temperature
Monoblock_model Ferrous/SS_impeller
Model nameProduct nameFlow rateTotal headLiquid temperature

Base-mounted_model

Model nameProduct nameFlow rateTotal headLiquid temperature
Base-mounted_model CAC_bronze
Model nameProduct nameFlow rateTotal headLiquid temperature
Base-mounted_model Stainless_steel
Model nameProduct nameFlow rateTotal headLiquid temperature
Base-mounted_model Ferrous/SS_impeller
Model nameProduct nameFlow rateTotal headLiquid temperature

Seal-Less_canned_pump

Model nameProduct nameFlow rateTotal headLiquid temperature
Seal-Less_canned_pump CAC_bronze
Model nameProduct nameFlow rateTotal headLiquid temperature
Seal-Less_canned_pump Stainless_steel
Model nameProduct nameFlow rateTotal headLiquid temperature

Seal-Less_magnetic_drive

Model nameProduct nameFlow rateTotal headLiquid temperature
Seal-Less_magnetic_drive Stainless_steel
Model nameProduct nameFlow rateTotal headLiquid temperature
